Canon 135mm f/3.5 LTM lens

Old and good.

For an index of all Leica-related articles click here.



The Canon 135mm f/3.5 LTM lens on the Leica M10.

Background:

While the 135mm focal length is a bit of a stretch on a rangefinder Leica when it comes to accurate focusing, it’s handy for picking out architectural details and adds little weight to the Leica M outfit. Arguably the best M body for this focal length is the film Leica M3 with its 0.91x viewfinder magnification, but the 0.73x in the digital Leica M10 does at a pinch unless you are close to the minimum focusing distance at full aperture. 135mm lenses are not hard to design so my expectations for performance of this 50+ year old optic are high.

Canon choices:

After the great success I have had with the bargain priced 35mm f/2 and 50mm f/1.4 LTM Canon optics, I thought I would hunt down one of their 135mm lenses. According to this rather sketchy web site there were no fewer than 8 versions of the lens made from October 1952 through January 1975, optically identical. Seems like Canon could not resist fiddling with the cosmetics and engraved details. The paint filled engraved markings on my copy look as new as the day they left the Japanese factory.

With lenses this old it makes sense to try and buy as late a model as possible and that site states that Version 8 had serial numbers between 106647 and 110715. The only physical difference appears to be the identification as “CANON LENS MADE IN JAPAN” as opposed to the earlier “Canon Camera Co., Inc. LENS MADE IN JAPAN” designation. If that’s correct then the serial number range is wrong as my lens has the “CANON LENS MADE IN JAPAN” designation with a serial number of 106503. That makes it Version 8, 1971 vintage. Most eBay listings are for the older Version 7, with Version 8 relatively scarce.

There are a great number of these listed on eBay, most in Japan, and the usual precautions apply. Any mention of ‘tiny balsam separation’, ‘tiny fungus’ or ‘tiny haze’ should see you rushing for the (not so tiny) exit. Mine is mint and cost $120 shipped from Japan, to which I had to add an odd sized 48mm UV protective filter for $12 and the Fotodiox Pro 6-bit coded LTM-to-M adapter for $16, making for a total cost of $148. A modest outlay reflecting the relatively low popularity of this focal length, one which I recall as being all the rage when I was a kid. Times change.

One dated aspect of this lens is the absence of a double helicoid focusing design, meaning the front of the lens and the aperture ring rotate when the lens is focused, necessitating dual aperture scales. This makes use with a polarizing filter difficult. In this regard the 35mm and 50mm Canon lenses are more modern designs, with non-rotating front elements. However, all three lenses have equally spaced aperture settings with full click-stops.

6-bit coding:

The M10’s firmware stores three 135mm Leica lenses:

  • 135mm f/2.8 Elmarit-M with goggles
  • 135mm f/4 Tele-Elmar-M
  • 135mm f/3.4 Apo-Telyt-M

Strangely, every available code table I have found omits codes for the 135mm f/4 Tele-Elmar which my tests disclose is a good choice of lens profile with the Canon lens in terms of absence of color fringing and vignetting. However, if you wish to use this profile there is an easy workaround. As all my other four lenses are 6-bit coded I would simply set the Main Menu->Lens Detection to the 135mm f/4 Tele-Elmar and leave the lens uncoded. Then when this sole uncoded lens is mounted on the camera, the software automatically switches to the manually dialed in lens, the 135mm Tele-Elmar. As long as the Lens Detection setting is not changed, every time an uncoded lens is inserted the camera sees it as the last lens dialed in manually – which is the 135mm Tele-Elmar! Neat.

In practice I have found the profile for the 135mm f/2.8 Elmarit-M to render the best edge detail, noticeably so with 100% pixel peeping in LRc. As my Fotodiox Pro adapter has the engraved pits for coding I coded it ‘001001’ which is the code for the Elmarit-M. Unlike with that Elmarit-M which brings up the 90mm finder frame, enlarged by the goggles, the coded Fotodiox adapter correctly brings up the 135mm frame lines. Then on import to LRc I will simply change the EXIF lens name in files with this lens designation to read ‘135mm Canon LTM’. So for those ‘experts’ who claim 6-bit coding for lenses longer than 50mm makes no difference, I can only say that is not the case in my experience. 6-bit coding makes a noticeable difference with the 135mm Canon LTM lens, and I recommend you do it.



The ‘001001’ code applied to the Fotodiox Pro adapter.
The Leica interprets this as a 135mm f/2.8 Elmarit-M.

Cam modification:



The non-rotating focus cam on the Canon
135mm lens. The actual cam is the brass
ring visible below, which contacts this pusher.

Canon did something very strange with the positioning of the ‘pusher’ focus cam on the rear of the lens. On a Canon LTM camera the focus index on the lens is displayed some 15 degrees to the right of the ‘Top Dead Center’ location of the pusher. Apparently someone at Canon thought it would be a smart idea to make the focus distance visible through the viewfinder though the reasoning behind this decision is lost in history. Which is as well as it’s an utterly useless design decision. This, however, poses a serious use issue with the lens when fitted with the Fotodiox LTM-to-M adapter on a Leica M body. Fotodiox correctly machines the single start thread on the adapter to position the focus index at TDC, as with any other LTM optic. However, this causes two problems:

  • The pusher cam almost misses the cam follower (roller) in the throat of the camera’s bayonet mount as it is offset to the left. This means rangefinder focusing is inaccurate.
  • The lens is located 0.0055″ too far forward on the bayonet adapter for correct focus even were the pusher to properly contact the cam follower. That means focus will be off significantly once the cam position is remedied.

In this illustration you can see just how offset to the left the cam is from the correct TDC position for contact with the cam follower – note the two black marks on the Scotch tape. The mark at the infinity focus line is where the center of the cam should be:



The cam’s offset. The leading edge
of the extended cam must be sloped or
concave to allow it to ease past the
roller when the lens is mounted,
otherwise it will jam and you risk
damage to the camera.

So first I had to add some J-B Weld epoxy at the leading edge of the cam to make sure of proper contact between cam and cam follower (roller) but also allowed some epoxy to be proud of the surface of the regular cam to correct for the focusing error. This dimension calls for an increase of but 0.0055″, a small amount, but critical for accurate rangefinder focusing. That’s the amount the pusher moves between the two black marks in the image above. J-B Weld has a fairly viscous consistency when the two parts are mixed and can be dabbed on to the leading edge of the cam and then allowed to cure for 24 hours. I needed three applications, meaning 72 hours, to build up the cam. No one said this process is fast.



The epoxy extension filed down for
accurate focus. The excess epoxy on the
inside of the cam pusher does not interfere
with anything, so I left it. A dab of
black matte paint finishes the job.

Having applied more epoxy than required on purpose, I then used a fine Nicholson miniature file to gradually file this layer down until the focus patch was correctly at infinity with the lens thus focused. I also made sure to file the new leading edge of the modified cam to a smooth slope to allow for gentle contact with the cam follower in the camera when the lens is mounted. Once cured J-B Weld epoxy is very hard so I expect it to wear well in use, especially as the sole contact the epoxied extension makes is with the benign rotating cam follower in the camera’s throat. The only friction occurs when the lens is mounted or removed. Checking focus accuracy at the minimum focus distance of 5 feet at full aperture confirms the fix is good. This is an extremely critical test and one you must do to make sure all is well when it comes to critical focusing. If this is not correct you will forever be blaming a splendid optic for poor performance. You cannot be too particular with a 135mm lens on a rangefinder Leica when it comes to focus accuracy as depth of field is very shallow and focusing errors (and camera shake!) are magnified compared to use with shorter lenses.

Phew! It took me the best part of a week to get this dead right. On my first attempt I filed away too much epoxy and had to build up the cam again. By the way, the lens has zero collectible value so it’s not like these modifications hurt anything. If anything they extend resale ownership to a large cadre of frugal Leica M owners who do not want to spend Leica-amounts on a relatively little used focal length.

Viewfinder interference:

Used without a lens hood the lens does not impinge on the 135mm frame in the finder of the Leica M10, except at its minimum focus distance of 1.5 meters/5 feet, where it just touches the lower right hand corner of the frame. In other words there’s no issue with finder blockage. Focused at infinity the lens protrudes just 4.0″ from the camera’s mount with a UV filter mounted. By comparison the 135mm Elmar is 4.8″ long and the Tele-Elmar is 4.4″ long. The Apo-Telyt is 4.1″ long. Considering it is not a retrofocus design Canon has done a fine job in limiting the length of the lens.

Red dome lens mounting index:

More shop work! As with the 21mm Voigtländer lens, I had to machine a recess for epoxy for a red dome mounting index in the rear serrated ring on the lens. The serrations do not provide an adequate mounting surface for the red dome. The stock index on the Fotodiox LTM-to-M adapter is far too hard to see and there is no tactile feedback for use in poor light. It bears repeating, if you are not experienced with machining operations, please delegate this task or risk marring your lens.



The lens is securely held in a machinist’s
vice on the table of the drill press.



The recess for the epoxy is drilled.
Note the stock index mark on the LTM-to-M adapter.

Set up time to get this right is 20 minutes, everything secured in place. Drill time is 30 seconds. Get the setup nailed and the drilling part is easy.



Now mounting the lens on the camera is easy.
Note the fine quality of Canon’s engravings and finish.

Canon vs. Leica:

The first impression when picking up the Canon lens is one of great solidity, likely the result of zero plastics in the construction, and weighing in at a chunky 15.4 ozs/435 grams. No rattles, no squeaks, just glass and metal alloy and superbly finished, with high quality engravings all around. Leica quality, in other words and the optic balances nicely on the very solid Leica M10. The diaphragm has no fewer than 10 leaves which should make for smooth out-of-focus areas and the click stops are firm, necessitating a hold on the broad focus collar to change apertures, otherwise the focus changes. The focus throw from infinity to 5 feet is extremely long, almost a full circle. Call it 345 degrees. So rapid focusing from here to there is not this lens’s forte, but careful alignment of the rangefinder images is. My guess is that Canon did this by design to enhance focus accuracy with the ‘iffy’ rangefinder at this focal length. Compare to Canon’s 35mm f/2 design with its extremely short focus throw of 90 degrees, because why add spurious fine focus tuning accuracy with a short focal length lens?



The 135mm Leitz Elmar and Tele-Elmar lenses.
Note the very long focus throw on the Elmar.

One of the significant advantages of the Canon lens over the Leitz 135mm f/4 Elmar (1960-65) or later f/4 Tele-Elmar (1965-85 and 1992-98) is for those (me!) who value 6-bit coding. There is no groove in the mounting flange of the Leitz lenses for addition of 6-bit codes so the lens has to be machined to add code pits. You cannot remove the rear flange for replacement with a 6-bit coded one as it’s retained internally, not with external screws. Reckon on $150 plus postage and waiting time to have the job done professionally. You hope. Paint the codes on the plain, stock flange and they will quickly wear off from friction between the lens and the mount on the camera’s body, so that’s not a solution. The other advantage is that at $148, all in, the Canon is far cheaper than the Leitz versions, though these do sell for fairly attractive prices, from $250 to $350, for unmolested copies.

One note – the early 135mm Leitz Elmar also came in an LTM version which means that a coded LTM-to-M adapter can be used for proper 6-bit coding. Given the reportedly small optical difference in performance between it and the successor Tele-Elmar it’s probably the best bet if you absolutely must have a Leitz 135mm lens, though it will encroach on the 135mm finder frame considerably more than is the case with the Canon. Add a lens hood and you are flying (half-) blind. Published tests suggest there’s little performance difference between the Canon and these two Leitz lenses. Do yourself a favor and keep your wallet heavy. Go with the Canon and be prepared to modify the cam as I show above. It’s not that hard if you have a modicum of mechanical skill.



The gigantic 135mm Elmarit with goggles.

There was also a 135mm f/2.8 Elmarit with giant goggles which completely defeats the concept of ‘small camera, small lens’. The goggles were added to enhance finder magnification for accurate focusing, and use the (magnified) 90mm finder frame. Talk of putting lipstick on a pig. This clunker was variously made between 1963 and 1997 and it’s hard to see going there.

Finally Leica made the 135mm f/3.4 Apo Telyt version, introduced in 1998, and seemingly recently discontinued, which makes you wonder why Leica still includes 135mm finder frames in its viewfinder. Leica added 6-bit coding somewhere around 2006 as standard, but the lens is silly priced used, so it is of little interest.

A more detailed resolution test appears here.

Some snaps to follow when I have had a chance to try this lens out on the M10.

Leitz 90mm f/2.8 Tele-Elmarit resolution test

A handy telephoto lens.

For an index of all Leica-related articles click here.



On the Leica M10. The 35mm f/2 Canon LTM is shown for size comparison.

When I first profiled the 90mm f/2.8 Leitz Tele-Elmarit lens I wrote: “But when it comes to size, one of the smallest and lightest 90mm lenses Leitz ever made was the second version of the Tele-Elmarit. The original ‘fat’ version weighed in at 335 grams (chromed brass mount) but when reissued in a ‘thin’ barrel (black anodized alloy and with 4 elements instead of the earlier 5) the weight dropped to 225 grams (8 ounces) and you gained a stop compared with all those Elmars as the lens, also made in Canada, is f/2.8. And the second, alloy barrel version is actually lighter than the 90mm f/4 Elmar-C, a lens intended for the Leitz/Minolta CL small body camera, which apparently works fine on regular M bodies. ”

Here are the test images taken at all apertures from f/2.8 down to f/16 – the lens is coded ‘000100’, where ‘1’ denotes a black paint filled pit. The lens is so distortion and vignetting free that there is no need to use a lens correction profile in LRc when processing images. These images are SOOC, and I used a monopod to minimize camera shake.



Test images from f/2.8 to f/16.

You can view all 8 images in medium size by clicking here.

To view full size 22mb originals click here. It’s a large file so be patient when downloading. You can zoom in on these to your heart’s content.

Conclusions?

  • Mild flare at f/2.8, disappears by f/4
  • At f/2.8 the whole frame is usable with a touch on the LRc ‘Dehaze’ slider and will easily make a large print with excellent resolution
  • At f/4 the resolution is high across the frame. Micro contrast is improved. Extreme corner details are well preserved.
  • Peak definition is reached at f/5.6 but there’s very little to choose between any aperture from f/4 to f/16
  • I can see no diffraction at any aperture
  • No meaningful color fringing at the edges of the frame at any aperture. The lens is 6-bit coded and replaceable rear flanges with coding pits can be found on eBay
  • There is no LRc lens correction profile available so I use the one for the 90mm f/2.8 Elmarit, but it’s not really necessary

By the way, disregard the f-stop data in the EXIF information. The M10, even with 6-bit coding adapter does a poor job of estimating the aperture used. (There is no electrical or mechanical link between the lens’s aperture setting and the camera, so Leica estimates the aperture based on the shutter speed and ISO used). Go by the file names, moving the decimal point in the last three digits one place to the left to see the aperture used. So, for example ‘110’ means f/11.

Any modern era Leitz or Leica lens for under $500 is something of a miracle, and I paid $454 for mine, shipped. The only sign of wear is some brassing (‘alloying’?) in one or two places on the mounting ring and focus collar which is as smooth as they come, and there’s some dust inside. While it’s not a lens I use often, and you have to concentrate on getting focus right at closer distances/wider apertures, it’s so small and light that taking it along ‘just in case’ is never an imposition. With the high resolution sensor in the M10 I instruct the camera to use a shutter speed of 1/4f, meaning 1/360th second, or faster, to preserve definition at its best. The engraved aperture markings on mine were rather faded on receipt – check the first image for ‘after’ – so I refilled them using a white Lacquer-Stik.

It’s a fine optic for picking out architectural details and the like and is recommended.

Leica M10 battery life

Not great, but it will do.

For an index of all Leica-related articles click here.

One common criticism of the Leica M10 is that the battery life is poor. When Leica finally slimmed down the M240 predecessor, which used an 1800mAh battery (meaning it could deliver 1.8 amps for one hour) the battery had to be smaller to work with the new svelte body which finally reverted to dimensions close to those of the M3. Battery life dropped a startling 39% to 1100mAh. But that raw statistic fails to tell the whole story as it’s reasonable to think that electrical efficiency of the M10 was improved as new components found their way inside the now once more beautiful body.






The Leica BP-SCL5 battery. Made by Varta in Indonesia.
Or is it Korea? I can find no indication of age.

Leica states “Batteries have only a limited service life. We recommend replacing them after around four years” (Manual p.203). Mine must be between 4-8 years old based on the years the camera was made, but still seem OK. This, especially at $200 a pop, is a ‘run it until it drops’ scenario.

Nonetheless, I confess to having been troubled by the small current capacity of the BP-SCL5 lithium ion battery which is still listed at B&H, though ‘Back ordered’. My mint M10 came with two original batteries and both appear to hold a charge well. There are no aftermarket alternatives currently. At first, to conserve battery life. I set the sleep time to the lowest setting, which is 2 minutes. After this time a first pressure was required on the shutter button to wake the camera, a process that takes some 2 seconds. Not good if you are street snapping and have to let one off – if you know what I mean – from the hip. And the shutter response of any M camera, film or digital, is known to be among the fastest ever made, so you want the camera ready at all times. So I decided too see how quickly a fully charged battery drained if the sleep timer was set to ‘off’, meaning the camera is always instantly ready but is using power to illuminate the finder frames and keep the rest of the electrical system primed for action.

After turning the camera on with sleep ‘off’, I checked the LCD at half hour intervals to see the charge remaining. The charge is displayed in 5% intervals so 50%, say, could well be 46% worst case, but you get a reasonably accurate set of data using this approach. I found that the battery lost 5% of its power every 30 minutes until it was completely drained 5 hours after start-up. The loss rate was linear.

Once the battery is drained the finder displays ‘bc’ when the shutter button is depressed, power being provided by the separate small rechargeable battery used to keep the time and date current. (That internal battery lasts 2 months if no main battery is installed. I shudder to think of the replacement cost, as replacement presumably requires partial dismantling of the camera). Now this is not a real world test as no pictures are being taken during the 5 hour discharge period.

Therefore I took the camera on walkabout, a session which lasted 66 minutes and saw the reported capacity fall to 80%. Worst case that means 76%. Extrapolation of battery life is easy given the linear rate of discharge noted previously. In that time I took 52 pictures which figures to a battery life as follows. I never used the LCD:

  • At 80% displayed, best case = 260 pictures (52/(1-0.80)). 5 hour life.
  • At 76% worst case = 216 pictures (52/(1-0.76)). 4.1 hour life.
  • The average is 238 pictures – or almost 7 rolls of film

So use of the camera compared with just leaving it unused but turned on makes relatively little difference to battery life. That means 5 hours if inactive but not sleeping and at least 4.1 hours in use with no sleep.

With my usage pattern that’s enough for more than a day’s work and with a spare in my pocket you can double those numbers. I do not recall snapping more than 3 rolls of 36 exposure film in one day over the past 50+ years. 7 rolls in a day is unlikely to ever happen, let alone 14 with the spare on hand. Having learned photography as an impecunious student I learned to never waste film and that habit remains in the digital age.

Here’s a perfect example of why the 2 second ‘wake from sleep’ delay is unacceptable in street snapping. This opportunity popped up right in front of me as the owner grabbed a handful of kibble to feed his beautiful golden retriever. I had to swivel and snap from the hip. 2 seconds later the picture was gone:



Feeding the pup. Leica M10, 35mm Canon LTM at f/8.

In conclusion, if you are a 5 images per second shot gunner using the M10 you should probably carry a spare battery or two. For sane photographers the M10’s small battery is just fine. With sleep disabled and taking one picture a minute the battery is good for some 4 hours and 250 snaps. Unless you are seeking to emulate garbage like that put out by the sainted Gary Winogrand in his later years, you should be OK.

In the M11 the battery grew in size again, reverting to the 1800mAh capacity found in the M240, likely attributable to further miniaturization of the innards of the camera. But paying twice the price of a mint M10 for this ‘nice to have’ feature does not solve for this snapper. Plus now instead of having to remove the baseplate to access the SD card you have to remove the battery. As the French would have it, ‘Plus ça change, plus c’est la même chose.’

The out of stock situation:

The fact that B&H shows the battery as being out of stock prompted me to check global listings for availability, and there is none. So it appears we have a replay of the M240 battery scandal where Leica has ceased manufacturing the battery four years after discontinuing the camera, essentially bricking an $8,000 piece of hardware. There is no aftermarket in batteries for either the M240 or the M10. And here is a manufacturer telling us that batteries last no more than four years but apparently discontinuing the product in a like timeframe. If the M10 battery is in fact discontinued I think it may be time for a good old-fashioned American class action suit against Leica to stop this disgraceful behavior. Meanwhile, the Leica company is a dishonorable inductee into this journal’s Hall of Shame.

21mm f/3.5 Voigtländer VM Color-Skopar Aspherical resolution test

An outstanding ultra-wide angle lens.

For an index of all Leica-related articles click here.



On the Leica M10. I added the red indexing dome and the
aperture index, the factory ones being useless.
The cheap 21mm finder is fitted.

When I first profiled the 21mm f/3.5 Voigtländer VM Color-Skopar Aspherical lens I wrote: “The lens is tiny and with a slim UV filter fitted weighs just 185 grams/6.5 ozs. For comparison the 35mm f/2 Canon LTM with bayonet adapter and UV filter comes in at 139 grams/4.9 ozs. Fit and finish are all metal and Leica quality, the focus collar resistance is just so and the apertures are in half click-stops through f/22. Small protuberances on the aperture ring make it easy to grasp. The black rimmed UV filter not only serves to protect the front element, it also masks off the poorly thought out chrome bayonet front ring which can only be a source of reflections and flare in bright lighting. The distance scale is marked in meters only and the depth of field scale is very hard to read, and only extends to f/11. The 50+ year-old Canon’s DoF scale is far superior in this regard. Not that big a deal as with a 21mm focal length lens almost everything is sharp near to far. ”

Here are the test images taken at all apertures from f/2 down to f/22 – I coded the lens to be the 21mm f/2.8 Elmarit-M. The code is ‘000001’, where ‘1’ denotes a black paint filled pit. I strongly advocate use of the excellent lens correction profile in LRc when processing images as it removes any trace of vignetting which is otherwise noticeable. Other than that the following images are SOOC.



Test images from f/3.5 to f/22.

You can view all 8 images in medium size by clicking here.

To view full size 22mb originals click here. It’s a large file so be patient when downloading. You can zoom in on these to your heart’s content.

Conclusions?

  • No flare at any aperture
  • At f/3.5 the whole frame is usable and will easily make a large print with excellent resolution
  • At f/4 the resolution is high across the frame. Micro contrast is improved. Extreme corner details are well preserved.
  • Peak definition is reached at f/8 but there’s very little to choose between f/4, f/5.6 and f/8
  • Modest diffraction sets in at the f/16 and f/22, but large prints are still OK
  • No meaningful color fringing at the edges of the frame at any aperture – that’s the 6-bit coding doing its magic
  • Vignetting and minor barrel distortion are perfectly corrected by the LRc lens correction profile

By the way, disregard the f-stop data in the EXIF information. The M10, even with 6-bit coding adapter does a poor job of estimating the aperture used. (There is no electrical or mechanical link between the lens’s aperture setting and the camera, so Leica estimates the aperture based on the shutter speed and ISO used). Go by the file names, moving the decimal point in the last three digits one place to the left to see the aperture used. So, for example ‘220’ means f/22.

A special lens that I bought on eBay in mint condition for a bargain price of just $400 with the lens hood. I’m selling the latter so my net cost will be just $340. Unless you get lucky expect to pay $450-500 used or $650 new without hood. The hood is a quite ridiculous $100. The crappy 21mm viewfinder added $26 and a 39mm UV filter was $10. Even at the new price the lens is a bargain. Avoid the older and cheaper f/4 version which is poorly suited to digital sensors. If you have more money than sense Leica will be pleased to empty your wallet with its offerings.

Leica M10 sensor cleaning

Easily done.

For an index of all Leica-related articles click here.

Fairly recent Nikon DSLRs (D700, D800) have an effective ‘sensor shaker’ which can be set to operate when the camera is powered on or off and helps remove all but the most stubborn dust particles from the sensor. This is particularly important with Nikon lenses which are poorly dust sealed – such as the the 16-35mm and 28-300mm AF-S versions which I use. These pump mighty quantities of air into the camera’s innards, along with any airborne dust, when the zoom ring is operated. It’s so bad you can feel the air rushing in if you remove the lens and zoom it close to your cheek. Quite why Nikon does not have its lens designers vent this blast of air to the outside beats me.

The Leica M10 has no sensor shaker, possibly because the compact body is already so packed with electronics and mechanical parts that there is no room for one. It’s probably the same reason that precludes installation of an IBIS system, which would be nice to have. But Leica has a clever workaround when it comes to sensor dust detection and removal. Go to the last page of the Main Menu on the LCD and click on ‘Sensor Cleaning->Dust Detection’. You will be directed to mount a lens stopped down to f/16 or f/22, defocused and pointed at a plain evenly lit surface. I used the 21mm Color-Skopar at f/22, focused on infinity, with my test wall just inches from the camera. Take a picture and you get this on the LCD screen:



Sensor dust disclosed. Click the image for a (yecch!) larger one.

Quite a bit of dust, something which can become visible in large plain areas in images, like expanses of sky. The picture on the LCD screen is rendered in the same orientation as the camera, as the red lens mounting index at left indicates.

Now go to Main Menu->Sensor-Cleaning->Open Shutter, first making sure your battery is fully charged. You do not want the shutter to close for lack of power when you are poking around in there. If the battery charge is below 40% a warning message requesting the battery be recharged will appear. Holding the camera upside down, LCD to the ceiling, blow in some air using a rubber blower bulb, directed at the sensor, being sure not to touch the surface protective glass, and redo the sensor dust image. Do not use compressed gas of any sort. The goal is to loosen dust particles so they can drop off, not blast them further into the innards of the camera. I got this:



Sensor dust gone.

Nice implementation by Leica and very easy to work with. The sensor is now clean as a whistle. If things had not improved I would have cleaned the sensor with an antistatic brush. Had that failed I would have resorted to a wet cleaning solution. I have used this product with success, and it leaves no residue, but despite the listing it does not come with a microfiber cloth, so make sure you have one. I cut a business card in half lengthwise and wrap the cloth around it. This makes for a flexible ‘wand’ and I spritz the tip of the cloth a couple of times, no more – you want moist not wet – with the solution and gently swipe the sensor’s cover glass this way and that. (I avoid Q-tips, finding them far too inflexible, meaning they risk damage to the protective glass on the sensor). Then a couple of puffs of air from the rubber bulb and you are done. This works for any digital sensor, not just the one in Leicas!

Because Leica M mount lenses do not have a zoom feature (the relatively benign variable focal length feature of the two Tri-Elmar lenses notwithstanding) the need for such sensor cleaning should be fairly rare. Further, when the lens is removed for changing, the sensor is protected by the shutter blades. So it’s not that easy for dust to get in there.

I had not checked for sensor dust since buying the camera second-hand 3 weeks ago, so only just got around to this, after noticing an out of focus blob or two in large smooth tone areas in LRc in this image, where the small aperture and short focal length of the lens emphasized dirt on the sensor.

If the surface you use to take the dust image is not evenly lit you will get a message ‘inhomogeneous (sic) image’. I got this more times than seemed right, despite using a flat, evenly lit, wall. Removing and reinserting the battery cured the issue.
