Some snaps.

For an index of all Leica-related articles click here.

Part I is here.

These were taken mostly at full aperture unless otherwise noted, with AutoISO. Absent minor correction of leaning verticals the images are pretty much SOOC. For ISOs of 3,200 and above I used LRc’s excellent ‘Denoise’ feature. It takes out digital noise without destroying definition. All originals were taken on DNG files, converted in LRc to JPG for this journal:

Autofocus on the little boy is spot on. 200mm, ISO 12,500.
Click the image for a larger version.

My previous experience with the Sigma 35mm f/1.4 Art lens suggested that Sigma’s quality control was less than stellar, with the autofocus being significantly off. Sigma makes the UD11 dock but it appears that it does not permit correction of autofocus errors, serving only to adjust manual focus collar rotation speed. It also allows downloading of the latest firmware but you can do that without a dock. Anyway, it appears I have lucked out as far as focus accuracy goes. The Leica SL2-S does not have a function to correct for lens autofocus errors, so that’s not a solution if your lens’s focus is off.

No evidence of chromatic aberration, 113mm, ISO 400.

Corner to corner resolution. 45mm, ISO 6,400.

The Declaration of Independence.
Stopped down to f/8. Outstanding resolution – check the big version.
65mm, ISO 6,400.
Click the image for a larger version.

Stopped down to f/4.8.
20mm, ISO 2,200.
Click the image for a larger version.

The outstanding in-camera correction of distortion and vignetting is very much visible here. Flare – check the light globe far right – is very well controlled.

Another example of fine flare control. 78mm, ISO 3,200.

Stopped down to f/8.
20mm, ISO 12,500.
Click the image for a larger version.

Performance at 20mm is exemplary, with little resolution gain from stopping down. There is no issue with using the lens wide open when it comes to rendering of details. This is a very high dynamic range image, testing the SL2-S’s (Sony BSI?) 24mp sensor to the limit. It acquits itself well, even though a 2019 design.

150mm, ISO 280.
Click the image for a larger version.

Check the detail rendering of the mesh behind the Hal Davis signage.

33mm, ISO 100.
Click the image for a larger version.

Obligatory brick wall. Again, the correction of distortion and vignetting is remarkable. Corner definition is all you could ask for.

200mm, ISO 200.
Click the image for a larger version.

There’s no need to stop down for best resolution at 200mm, as the above proves.

A few more snaps to round out this piece. The outdoors were very smoky from forest fires and an occasional touch on LRc’s Contrast slider was called for, though the lens delivers good contrast otherwise.

95mm, ISO 560.
Click the image for a larger version.

Check the definition of the lettering at the lower right in the large version.

123mm, ISO 140.

31mm, ISO 1,600.

71mm, ISO 1,600.

191mm, ISO 100.

A touch of Saul Leiter. 91mm, ISO 200.

Conclusion: A fine ‘walk about’ lens, small, light with no excuses needed for performance at any aperture. This one optic easily replaces two zooms or half a dozen primes in your kit bag. As the last image in Part I discloses the 20-200mm Sigma is also a capable macro lens. A fine optical accomplishment by the designers in Aizu, Japan. Sharing the tasks of aberration correction between the hardware team (coma, spherical and chromatic aberrations) and the software team (distortion and vignetting) is surely the wave of the future. Kudos, also, to Leica for updating the firmware for the SL2-S to accommodate the Sigma zoom. The lens was introduced after the SL2-S was discontinued (January 2025).

Not your father’s superzoom

For an index of all Leica-related articles click here.

The Sigma 20-200mm zoom on the Leica SL2-S.

Background:

The Sigma 20-200mm f/3.5-6.3 DG Contemporary Lens in L-Mount easily qualifies as a ‘superzoom’, with its 10:1 zoom range. Boasting no fewer than 18 elements in 14 groups – a testimony to computer-aided design – it weighs in at a modest 19.4 ounces. Four of those elements are aspherical. This relatively low weight is attributable to Sigma’s use of polycarbonate plastics for much of the chassis, in lieu of the typical construction of Leica SL lenses which come in all metal construction. The bayonet mount is stainless steel and the innards are made of light alloys. It’s no secret that Sigma’s optical designs find their way into many Leica branded L mount lenses, where metal is added and the price is hoiked by 50-100%. German labor costs, you understand.

Optics:

Generous use of aspherical surfaces – outlined in red.

FLD? Standing for ‘F’ Low Dispersion, the material is claimed to have performance equivalent to fluorite glass, but at a more affordable price. Its optical characteristics apparently allow excellent correction for residual chromatic aberration, while its lower density compared to traditional optical glass allows lighter lenses.

SLD? Special Low Dispersion glass enables the mass production of high-quality lenses; it’s a material which reduces optical aberrations at lower cost than fluorite glass.

Macro capability:

The Sigma 20-200 is available in Sigma branding only and, as far as I can tell, is the L mount full frame lens with the widest zoom range. Not content with making a lens with an extraordinary zoom range, Sigma added a macro capability with the lens focusing down to half life-size in the 20-85mm zoom range. At 200mm the maximum reproduction ratio is 1:3, or one-third life size. At 20mm the lens to object distance is really too small but at 85mm it makes for a very useful macro lens and even at 200mm the macro capability is substantial.

Feel and controls:

The focus ring, which is an electronic ‘fly by wire’ design, not a mechanical one, is butter smooth. There are no focus stops, just continuous rotation, and the lens’s length does not change as it is focused. It feels metallic.

The zoom ring, rather counterintuitively, has to be rotated counterclockwise to lengthen the focal length. One adapts quickly. It’s a tad stiffer than I would ideally like but expect it will loosen up with use. It feels rubberized with somewhat coarser fluting than on the focus ring.

Despite the extensive use of plastics for the focus and zoom collars the overall feel of the lens is that of a high quality optic. Amazingly, when fully extended at 200mm (7.5″ lens length) there is absolutely no play in the extended barrel. Well done, Sigma!

Autofocus and lens switches:

Until now all my lenses for the Leica SL2-S have been either Leica M mount lenses used with Leica’s competent adapter, or old manual focus Nikkors used with an inexpensive aftermarket Nikon F to L mount adapter. The Sigma is my first autofocus lens for the SL2-S. Mine was purchased new from B&H and came with a pouch, lens hood and front and rear caps. The filter mount size is 72mm. There are two switches on the lens – AF/MF and a zoom lock at 20mm. While my sample does not extend under gravity, wear and age may yet make the lock switch useful. The lock can be unlocked using the switch or with a twist of the zoom ring. Nice. The diaphragm has nine blades.

The lens does not maintain focus as it is zoomed, but AF makes this a non-event. I doubt the AF is fast enough for sports photography but for my intended uses – street snapping and travel – it’s fast enough. The AF motor is silent.

Manual focus:

Switch to MF and a touch on the focus collar brings up a magnified image in the finder of the SL2-S making nailing focus trivial. (This feature can be turned off in the SL’s controls). Touch the shutter release to revert to normal magnification in the EVF. Beautifully implemented.

The manual focus option is intriguing, Turn the focus ring rapidly and you get from infinity to closest focus in a half turn of the ring. However, turn the focus collar slowly and it takes a full two turns to span the focus range. This is especially handy for focus stacking of multiple macro images where one would usually use a rack to drive the whole camera + lens assembly to and from the subject, as using the focus collar the minute focus changes required between images are almost impossible to apply using a lens with a regular focus collar. With the fine focus changes possible with slow movements of the Sigma’s collar focus stacking is readily achieved. A brilliant design of ‘fly-by-wire’ electronic focusing.

The Contemporary lens line:

Sigma has three lens lines. The Art series lenses are mostly large aperture and bulky, with high optical quality and fixed maximum apertures in the zooms. I owned the 35mm f/1.4 and it remains the sharpest lens I have used. The Sport series mainly comprises long zooms and fixed focus optics, with the zooms having a fixed maximum aperture. Finally, the Contemporary series, which includes the 20-200mm zoom, is the budget line and boasts 14 full frame primes and four zooms, two of which have fixed maximum apertures – the 16-28mm and the 28-70mm, both f/2.8. That’s not the case here where the maximum aperture at 20mm of f/3.5 falls to f/6.3 (2 stops slower) at 83.3mm and up. I suppose that compromise keeps weight and bulk down. Contrast that with my current Nikon superzoom, the 28-300mm AF-S Nikkor G, whose apertures range from f/3.5 to f/5.6, with a similar 10:1 or so zoom range. With the Sigma you get the far more useful 20mm at the wide end, sacrificing 100mm off the long end. That works for me. Sigma claims the lens is weather sealed, with seven internal seals, and there is also an external rubber O-ring on the bayonet mount.

Country of origin:

From the booklet included with the lens.

Image stabilization:

There is no image stabilization in the lens, but the Leica SL2-S’s IBIS does the trick. Also, in the L mount version distortion correction – barrel and wave at the wide end and pincushion at the long one, along with substantial vignetting at the shorter focal lengths – is done in camera. That’s a smart approach which further frees up the designer and likely reduces weight and bulk. See below for examples of how well this works.

Weight and bulk:

And how do weight and bulk compare between the SL2-S with the 20-200 and the Nikon D800 with the 28-300mm? Both are fitted with Upstraps, SDHC cards, a lens hood and a UV protective filter:

Nikon D800 with the 28-300mm AF-S zoom.

The Sigma on the Leica SL2-S.

While the Sigma lens weighs just over one pound the heavy weight of the mirrorless SL2-S rather offsets the weight savings compared with a conventional, flapping mirror DSLR.

Aperture control:

There is no aperture setting ring on the lens. Apertures are changed with the rear thumbwheel on the camera’s body.

Automatic distortion correction:

The Leica SL2-S automatically applies in camera distortion correction, and it is spectacularly good, especially when the peculiar waveform + pincushion distortion of the native lens is taken into account at the shorter focal lengths, not to mention the significant corner vignetting at those focal lengths. Look at the parallelism of the top of the bookcase with the edge of the frame, and note the absence of any vignetting:

At 20mm.

At 200mm.

Turn on ‘Enable Profile Corrections’ in LRc and the results are ghastly – this setting would only be used with cameras which do not provide automatic distortion correction. The reason they are so poor is that profile correction is being applied twice – once in the camera and then again in LRc. What these images disclose is just how severe the distortion and vignetting of the native lens really are, and how perfectly the Leica corrects them. LRc has the lens correction profile for the Sigma lens – I believe it would have to be used with certain Sony mirrorless bodies which do not apply in camera distortion and vignetting correction, for the Sony E-mount version of this lens.

At 20mm with LRC’s ‘Enable Profile Corrections’ enabled.

At 200mm with LRC’s ‘Enable Profile Corrections’ enabled

Definition at full aperture:

I’ll publish regular street snaps in a later post; meanwhile these are at full aperture at the extremes of the zoom range:

At 20mm, f/3.5.
Click the image for a larger version.

At 200mm, f/6.3.
Click the image for a larger version.

Best use:

This is a perfect travel lens. It’s also excellent for Macro – see below. One lens which does it all. If you want lightning fast AF for sports photography, or need large apertures for poor light or shallow depth-of-field look elsewhere.

A quick macro example:

Using the ‘slow focus’ function of the focus ring (see ‘Manual focus’, above) I exposed 36 images of the wild flower using MF:

Lesser Burdock. 50% crop of the original image.
Click the image for a larger version.

The ISO was set at 100, and the Sigma’s aperture at f/16. Focal length was 129mm. Lighting was from three strobes. The result is a focus stacked image using 36 differentially focused images, stacked using Helicon Focus. I think you may agree the definition is half decent.

More in Part II.
